The OnX6 Arc Series is the perfect combination of performance and aesthetics. The latest generation of the OnX6 series is the most elite LED light bar utilizing high-speed spot reflectors for increased performance and versatility. We use next-generation LEDs that provide 37% greater distance over that last up to 50,000 hours and have a 5000K light temperature; this mimics natural daylight for better trail recognition and less eye fatigue. Beautifully arched to fit the contour of your bumper or windshield, the Arc Series redefines the capabilities of the standard/traditional LED light bar.

Product Variants:

OnX6 30 Inch Arc LED Light Bar (Spot Beam)

• Dimensions: 30" (L) x 4.29" (D) x 2.69" (H)

• Weight: 11.45 lbs

• Brightness: 32,070 Lumens (High), 25,610 Lumens (Low)

• Power Consumption: 278W (High), 222W (Low)

• Amperage: 21.7A (High), 17.1A (Low)

• Lighting Quantity: 18 LEDs

• Lens Material: Hardcoated Polycarbonate

• Housing: Black Aircraft-Grade Aluminum

• Mounting Hardware: Stainless Steel Brackets (Included)

• Standards Compliance: IP69K Waterproof, MIL-STD810G, IK10 Impact Resistant

• SKU: 524001

OnX6 40 Inch Arc LED Light Bar (Spot Beam)

• Dimensions: 40" (L) x 4.29" (D) x 2.69" (H)

• Weight: 15.05 lbs

• Brightness: 39,220 Lumens (High), 32,760 Lumens (Low)

• Power Consumption: 340W (High), 284W (Low)

• Amperage: 26.8A (High), 22.4A (Low)

• Lighting Quantity: 24 LEDs

• Lens Material: Hardcoated Polycarbonate

• Housing: Black Aircraft-Grade Aluminum

• Mounting Hardware: Stainless Steel Brackets (Included)

• Standards Compliance: IP69K Waterproof, MIL-STD810G, IK10 Impact Resistant

• SKU: 525001

OnX6 50 Inch Arc LED Light Bar (Spot Beam)

• Dimensions: 50" (L) x 4.29" (D) x 2.69" (H)

• Weight: 18.65 lbs

• Brightness: 39,910 Lumens (High)

• Power Consumption: 346W (High)

• Amperage: 28.2A (High)

• Lighting Quantity: 30 LEDs

• Lens Material: Hardcoated Polycarbonate

• Housing: Black Aircraft-Grade Aluminum

• Mounting Hardware: Stainless Steel Brackets (Included)

• Standards Compliance: IP69K Waterproof, MIL-STD810G, IK10 Impact Resistant

• SKU: 523003

OnX6 30 Inch Arc LED Light Bar (Driving/Combo Beam)

• Same specifications as Spot Beam variant but with Driving/Combo Beam Pattern

• SKU: 524003

OnX6 40 Inch Arc LED Light Bar (Driving/Combo Beam)

• Same specifications as Spot Beam variant but with Driving/Combo Beam Pattern

• SKU: 525003

OnX6 50 Inch Arc LED Light Bar (Driving/Combo Beam)

• Same specifications as Spot Beam variant but with Driving/Combo Beam Pattern

• SKU: 523004

OnX6 30 Inch Arc LED Light Bar (Wide Cornering Beam)

• Same specifications as Spot Beam variant but with Wide Cornering Beam Pattern

• SKU: 523004

High-intensity LED lighting for superior visibility
Durable aircraft-grade aluminum housing with Mil-Spec Hard Anodize
Multiple beam patterns to suit different driving conditions
Overvoltage protection and IP69K waterproof rating
Universal mounting compatibility with stainless steel brackets

Each OnX6 Arc LED Light Bar model is designed to withstand the toughest conditions while providing maximum brightness and efficiency for off-road adventures. Choose the size and beam pattern that best fits your needs!

NOTE: This bar does not come with a wiring harness. You will need PN:640119 (Hi-Power w/Mode Switch 2-light max wiring harness)
